GPS provides 3-minute tsunami alerts

Friday, 24 May, 2013


The use of GPS to measure ground deformation could provide accurate warning of tsunamis just a few minutes after an earthquake strikes.

Researchers have shown that, by using global positioning systems (GPS) to measure ground deformation caused by a large underwater earthquake, they can provide accurate warning of the resulting tsunami in just a few minutes after the earthquake onset. For the devastating Japan 2011 event, the team reveals that the analysis of the GPS data and issue of a detailed tsunami alert would have taken no more than three minutes. The results were published on 17 May in Natural Hazards and Earth System Sciences, an open access journal of the European Geosciences Union (EGU).

Most tsunamis, including those in offshore Sumatra, Indonesia in 2004 and Japan in 2011, occur following underwater ground motion in subduction zones, locations where a tectonic plate slips under another causing a large earthquake. To a lesser extent, the resulting uplift of the sea floor also affects coastal regions. There, researchers can measure the small ground deformation along the coast with GPS and use this to determine tsunami information.

“High-precision real-time processing and inversion of these data enable reconstruction of the earthquake source, described as slip at the subduction interface. This can be used to calculate the uplift of the sea floor, which in turn is used as initial condition for a tsunami model to predict arrival times and maximum wave heights at the coast,” says lead author Andreas Hoechner from the German Research Centre for Geosciences (GFZ).

Japan could have had earlier warning

In the paper, the researchers use the Japan 2011 tsunami, which hit the country’s northeast coast in less than half an hour and caused significant damage, as a case study. They show that their method could have provided a detailed tsunami alert as soon as three minutes after the beginning of the earthquake that generated it.

Boat dragged inland during the Japanese tsunami in 2011

Boat dragged inland in Akahama, Japan by the 2011 tsunami. Photo: Stephen Vaughan

“Japan has a very dense network of GPS stations, but these were not being used for tsunami early warning as of 2011. Certainly this is going to change soon,” states Hoechner.

The scientists used raw data from the Japanese GPS Earth Observation Network (GEONET) recorded from a day before to a day after the 2011 earthquake. To shorten the time needed to provide a tsunami alert, they only used data from 50 GPS stations on the northeast coast of Japan, out of about 1200 GEONET stations available in the country.

Traditional techniques fall short

At present, tsunami warnings are based on seismological methods. However, within the time limit of 5 to 10 minutes, these traditional techniques tend to underestimate the earthquake magnitude of large events. Furthermore, they provide only limited information on the geometry of the tsunami source.

Both factors can lead to underprediction of wave heights and tsunami coastal impact. Hoechner and his team say their method does not suffer from the same problems and can provide fast, detailed and accurate tsunami alerts.

The next step is to see how the GPS solution works in practice in Japan or other areas prone to devastating tsunamis. As part of the GFZ-led German Indonesian Tsunami Early Warning System project, several GPS stations were installed in Indonesia after the 2004 earthquake and tsunami near Sumatra and are already providing valuable information for the warning system.

“The station density is not yet high enough for an independent tsunami early warning in Indonesia, since it is a requirement for this method that the stations be placed densely close to the area of possible earthquake sources, but more stations are being added,” says Hoechner.

This research is presented in the paper ‘Instant tsunami early warning based on real time GPS - Tohoku 2011 case study’, available online, free of charge, at: http://www.nat-hazards-earth-syst-sci.net/13/1285/2013/nhess-13-1285-2013.html.
